A Humbucker By Any Other Name

Posted on by
This is probably what you pictured when you read the word “humbucker”…

The term humbucker probably brings to mind the “Gibson” sound, or rather – and more specifically –  the “Patent Applied For” or “P.A.F.” sound. The pickups made by Gibson in this narrow time frame, spanning from the late ’50s to early ’60s (though the patent was officially awarded in 1959) have become synonymous with what a humbucker “should” sound like. Never mind the fact that rarely would you ever find two P.A.F.-era pickups that share the same exact sound, but that’s a whole other topic unto itself. Because of this, what is now considered a traditional humbucker has become as much form as it is function.

Continue reading →

Size DOES Matter

Posted on by

When replacing potentiometers (pots), there are differences in shaft size you’ll need to be aware of. The shaft we are referring to is the part of the pot with threading that sticks through the guitar top or pickguard where it is held down by a threaded nut. First, there are differences between metric vs imperial shaft diameters, with metric being about 1/4” in diameter and imperial being 3/8” in diameter. In my opinion, if you have the smaller diameter shafts, it’s worth reaming out the hole to accept a 3/8” shaft. The larger diameter pots are typically higher quality in all aspects. Fortunately, you will usually only find small diameter pots on the cheapest guitars. Always use a reamer to enlarge the holes because a twist tip drill can crack the wood of the guitar top.

Continue reading →

Welcome To The DULLhouse

Posted on by

We get asked all the time, “Why does my old pickup sound dull?” There are many reasons the tone can suffer on vintage pickups.

These p'ups aren't just *playing* dead... They're dead!
These p’ups aren’t just *playing* dead. They’re actually dead!

We can’t resurrect or improve every beaten, tired, old pickup that we come across. Some of them, like the ones seen above, are just too far gone. Only a complete rebuild, with brand new parts could bring them back to life, but at that point, you may as well just replace it! You can’t shine a turd, as they say — and even if you could, you’d still just have a shiny turd. But, just maybe, your dull sound isn’t the turd you thought it was, so in this edition, we’ll address the possible causes and potential solutions.

Continue reading →

Tone Chasin’: The Skinny on Capacitors and Potentiometers (Or Caps and Pots)—Part 2

Posted on by

By Jason Lollar

In my previous post, I wrote about choosing the best pots for your sound (If you haven’t done so already, you can read it HERE). In this post, I will focus on capacitors (or caps), the different types/values, and how they work to affect and influence your guitar tone.

Choosing the Right Capacitors

Tone capacitors are wired to the tone pot so the signal from the guitar pickup will pass high frequencies to ground when the tone pot is rolled down. The higher the value of the cap the wider the range of frequencies that get rolled off to ground. With lower value caps only the highest frequencies get cut off.

As a secondary effect, the higher the value cap, the more frequencies are rolled off with a shorter throw on the pot. So, with a high value cap the tone control can act more like an off or on switch. With a lower value cap, you can throw a lot farther on the pot, so you can dial in the tone with finer adjustment.

Continue reading →

Tone Chasin’: The Skinny on Capacitors and Potentiometers (Or Caps and Pots)—Part 1

Posted on by

Tone Chasin’: The Skinny on Capacitors and Potentiometers (Or Caps and Pots)—Part 1

By Jason Lollar

Finding your guitar tone involves a mix of science and voodoo. This alchemy includes the role of capacitors and potentiometers, also known as caps and pots. In this article, we focus on pots, and separate fact from fiction and explain how they are typically used to give you greater tone and volume control.

Choosing the Right Control Pot

There are some standard assumptions concerning pot and cap values and their use for different pickup designs, like single coils or humbuckers. These conventions can be useful, but you don’t need to blindly follow them.

Take the pot values first. Pots with higher resistance — like 500K compared to 250K — prevent higher frequencies from bleeding through to ground more than lower ohm pots. This means a 500K pot provides a brighter overall tone than a 250K pot. Higher ohms also give you a cleaner and punchier sound on the bass strings.

Continue reading →
